Sensitization: in vitro KeratinoSens®, OECD 442 D (GLP)

KeratinoSens is the in vitro skin sensitization assay for the second key event of the adverse outcome pathway: activation of the Keap1-Nrf2-ARE pathway in keratinocytes. It is an animal-free route to the sensitization endpoint that ISO 10993-10:2021 recognises for suitable materials.

SKU: GRK-4002-03
Availability:
Price: Call for pricing

When this test applies

Sensitization is required for essentially every patient-contacting device under ISO 10993-1:2025. ISO 10993-10:2021 allows in vitro methods in place of the animal assays where the material falls within their applicability domain. KeratinoSens addresses keratinocyte activation (key event 2); a defensible in vitro conclusion normally combines it with a second method covering another key event, such as kDPRA for protein reactivity, which is why we recommend running the two together.

When to run it

Early — before committing to the guinea pig maximisation test. At 8 weeks it is faster than GPMT, materially cheaper, and avoids an animal study where the result is clear. Where a material is outside the applicability domain (for example certain metals, strongly coloured or highly insoluble extracts), confirm that with a scientist first; a result you cannot defend sends you to GPMT anyway.

What a pass tells you

That luciferase induction stayed below the 1.5-fold threshold at non-cytotoxic concentrations with no dose-response — a negative prediction for keratinocyte activation under OECD 442D. Read with a complementary assay, that supports a non-sensitizer conclusion under ISO 10993-10.

What it does not tell you

A single in vitro assay addresses one key event, not the whole sensitization pathway, and a negative result on its own is rarely sufficient for a submission. It also says nothing about irritation, cytotoxicity, systemic effects or genotoxicity.

Method

Testing per OECD 442D under ISO 10993-10:2021. The device extract is applied in a concentration series to an immortalised human keratinocyte reporter cell line carrying a luciferase gene under ARE control. After exposure, luciferase induction and cytotoxicity are measured; a positive prediction requires induction of 1.5-fold or more below the cytotoxicity limit with a concentration-response. Extraction ratio follows ISO 10993-12: 6 cm²/mL for material under 0.5 mm thick, 3 cm²/mL at 0.5 mm or thicker, or 0.1 to 0.2 g/mL where surface area is indeterminate.

Where it runs

Testing is performed to Groenakker protocols at an ISO/IEC 17025 accredited, GLP certified laboratory in Groenakker’s network, and the report is issued under Groenakker’s ISO 13485:2016 certified quality system, in Groenakker’s report template or in your document template on request at no extra cost.

Usually ordered alongside

A second in vitro method covering another key event (kDPRA, OECD 442C) to build the weight of evidence, with GPMT (GRK-4002-01) as the fallback where in vitro does not apply. Cytotoxicity and irritation complete the surface-contact baseline.

Products specifications
SubcontractedYes
StandardsISO 10993-10:2021
EndpointSensitization
Method detail
Turnaround8-9 weeks
Test systemIn vitro - immortalised human keratinocyte reporter cell line
MethodKeratinoSens skin sensitisation assay, OECD 442D
ExtractionTest material prepared per OECD 442D. Extraction ratio per ISO 10993-12: 6 cm2/mL for material under 0.5 mm thick, 3 cm2/mL at 0.5 mm or thicker, or 0.1-0.2 g/mL where surface area is indeterminate.
Acceptance criteriaPer OECD 442D, a prediction is positive when luciferase induction reaches 1.5-fold or more below the cytotoxicity limit with a dose-response; ISO 10993-10 permits this in vitro route in place of an animal assay where the material is suitable.
DeliverableGLP-compliant final report with raw data, issued in Groenakker’s report template or in your document template on request at no extra cost, under Groenakker’s ISO 13485:2016 certified quality system.
*
*
*
