Physical Evaluation: Particulate Analysis - Surface Extraction, Method 1 Light Obscuration (GLP)

Particulate analysis counts and sizes the particles a device surface releases. The surface is extracted and the extract is measured by light obscuration, with cumulative counts reported at 10 µm and 25 µm.

SKU: GRK-8001-01D
Availability:
Price: Call for pricing

When this test applies

Where particulate burden matters clinically — devices in the fluid path, devices delivering to the vasculature, and devices where a specification or a predicate sets a particulate limit. It is a device-specification test rather than an ISO 10993 biological endpoint.

When to run it

On the finished, packaged device, and after any change to surface finish, cleaning or packaging. Particulate counts are a manufacturing and handling attribute, so they move when the process moves.

What a pass tells you

That cumulative particle counts at 10 µm and 25 µm fall within the limits for your dosage form or device specification. The comparison is against your specification — so the result is only as meaningful as the limit you have justified.

What it does not tell you

Light obscuration counts and sizes particles; it does not identify them. If a count is out of specification, characterising what the particles are is separate analytical work. It also says nothing about any biological endpoint.

Method

Testing per USP <788> Method 1. The device surface is extracted and particle counts are determined on the extract by light obscuration, with cumulative counts reported at 10 µm and 25 µm.

Where it runs

This method is domestically sourced. The laboratory is ISO/IEC 17025 accredited and GLP certified, and the report is issued under Groenakker’s ISO 13485:2016 certified quality system, in your document format.

Usually ordered alongside

Gas pathway analysis for breathing-circuit devices, and chemical characterisation where the particulate finding needs chemical follow-up.

Products specifications
SubcontractedYes
StandardsUSP <788>
EndpointParticulate Matter
Method detail
Test systemAnalytical - light obscuration particle counter
MethodParticulate analysis, surface extraction, Method 1 light obscuration
ExtractionSurface extraction of the device; particle counts determined on the extract.
Acceptance criteriaPer USP <788> Method 1, cumulative counts at 10 micrometres and 25 micrometres are reported against the limits for the dosage form or device specification.
DeliverableGLP-compliant final report with raw data, issued in Groenakker’s report template or in your document template on request at no extra cost, under Groenakker’s ISO 13485:2016 certified quality system.
Testing locationDomestic (US)
*
*
*
